Meningvax / Scientific Atlas Research Edition 01
The Science Behind Meningitis

Where biology meets the science of prevention.

Meningitis is more than a clinical diagnosis. It is a complex interaction between infectious pathogens, the protective membranes of the central nervous system, and the human immune response. Explore its biology, vaccination, diagnostic approaches, and the research advancing disease prevention.

Scientific Scope Microbiology / Immunology / Neuroscience
01/06
FIG. 01 — CNS PROTECTION Conceptual anatomical study
Brain and protective meninges illustration An artistic scientific illustration of the brain surrounded by protective meningeal layers. Not drawn to anatomical scale.
LAYER / 01 Dura Mater
LAYER / 02 Arachnoid Mater
LAYER / 03 Pia Mater
Biological System Central Nervous System

Brain · Spinal cord · Meninges

Research Focus Infection & Immune Response

Pathogens · Inflammation · Protection

MENINGVAX — SCIENTIFIC EXPLORATION
02 / Disease Mechanisms
Microbiology · Pathogenesis · Immunology

From pathogen to inflammation.

Meningitis develops when the protective membranes surrounding the brain and spinal cord become inflamed. Its underlying mechanisms differ according to the infectious organism or non-infectious trigger. Understanding these processes is central to prevention, diagnosis, and research.

Mechanism Atlas / Figure 02

Example: Bacterial Meningitis Pathogenesis

SCHEMATIC MODEL
NOT TO SCALE
Four stages of bacterial meningitis pathogenesis A conceptual pathway showing nasopharyngeal colonization, bloodstream invasion, central nervous system entry, and meningeal inflammation in certain forms of bacterial meningitis. 01 02 03 04 Colonization Bloodstream CNS Entry Inflammation Mucosal surface Possible dissemination Protective barrier Meningeal response
Figure 02. Simplified conceptual model of hematogenous spread in certain bacterial meningitis infections. Pathogen-specific routes and mechanisms vary. The illustration is not intended to represent every cause of meningitis.
01 / ENTRY

Pathogen Colonization

Certain bacterial pathogens, including Neisseria meningitidis, can colonize the human nasopharynx. Colonization may remain asymptomatic or, in some cases, precede invasive disease.

02 / INVASION

Systemic Dissemination

Some pathogens can enter the bloodstream and cause invasive infection. Survival within the host depends on bacterial virulence factors and immune defenses.

03 / CNS ACCESS

Protective Barrier Crossing

In certain infections, microorganisms reach the central nervous system across protective barriers. The mechanisms depend on the pathogen and the host.

04 / RESPONSE

Meningeal Inflammation

Recognition of microbial components triggers inflammatory signaling. In severe bacterial meningitis, this response may contribute to tissue injury and neurological complications.

Disease Classification / 02.1

One anatomical site. Multiple causes.

Meningitis is defined by inflammation of the meninges, not by a single microorganism. Different infectious agents and non-infectious conditions can produce meningeal inflammation, with important differences in diagnosis, treatment, and prevention.

01

Bacterial Meningitis

A potentially life-threatening form of meningitis caused by bacteria such as Neisseria meningitidis, Streptococcus pneumoniae, and Haemophilus influenzae. Suspected acute bacterial meningitis requires urgent medical assessment and treatment.

Explore bacterial meningitis
02

Viral Meningitis

Caused by a range of viruses, including enteroviruses and herpesviruses. Many cases are self-limited, although disease severity varies by pathogen, age, and immune status.

Explore viral meningitis
03

Fungal and Other Infectious Forms

Fungal, parasitic, and other infections can cause meningitis. Some are particularly important in people with weakened immune systems or specific exposures.

Explore infectious causes
04

Non-Infectious Meningitis

Meningeal inflammation may also occur in association with certain medications, autoimmune conditions, malignancies, or other non-infectious processes.

Explore non-infectious causes
03 / Vaccine Science Immunology · Prevention · Research

The meningitis vaccine atlas.

Vaccination has transformed the prevention of several major causes of bacterial meningitis. Different vaccine platforms target specific pathogens or meningococcal serogroups, making pathogen-specific protection a central principle of meningitis prevention.

Vaccine-induced immune recognition Conceptual immune recognition illustration showing a central antigen and surrounding antibody-like structures. It represents principles of adaptive immunity rather than a molecularly accurate structure. IMMUNE RECOGNITION ADAPTIVE RESPONSE
Fig. 03 / Antigen recognition / Conceptual model
The Immunological Principle

Preparing the immune system before exposure.

Vaccines introduce selected antigens or antigen-encoding components that stimulate protective immune responses. Depending on the vaccine, this may involve antibody production and the generation of immune memory, helping the body respond more effectively to future exposure.

Recognition Immune cells identify vaccine antigens.
Protection Protective responses can reduce the risk of targeted disease.

Four major vaccine groups

Each vaccine group addresses a particular bacterial target. Their protection, formulations, and recommended use differ.

VACCINE GROUP / 01

MenACWY

Neisseria meningitidis

Meningococcal conjugate vaccines targeting serogroups A, C, W, and Y. They help prevent invasive meningococcal disease caused by these serogroups.

Explore MenACWY
VACCINE GROUP / 02

MenB

N. meningitidis serogroup B

Protein-based vaccines designed to protect against meningococcal serogroup B disease. Strain coverage depends on the antigens and vaccine formulation.

Explore MenB
VACCINE GROUP / 03

Pneumococcal

Streptococcus pneumoniae

Pneumococcal vaccines protect against selected pneumococcal serotypes, reducing the risk of invasive pneumococcal disease, including pneumococcal meningitis.

Explore Pneumococcal Vaccines
VACCINE GROUP / 04

Hib

Haemophilus influenzae type b

Hib conjugate vaccines help prevent invasive infections caused by type b strains, including meningitis. They are widely incorporated into childhood immunization programs.

Explore Hib Vaccination
Comparative Vaccine Science / 03.1

Different targets. Distinct protection.

Vaccine selection is determined by the target organism, its antigenic diversity, the relevant vaccine formulation, and age- or risk-based recommendations. No single vaccine prevents every form of meningitis.

Vaccine Group Target Scientific Principle
MenACWY Meningococcal A, C, W, Y Polysaccharide-protein conjugation
MenB Meningococcal B Protein-based antigen targeting
Pneumococcal Selected pneumococcal serotypes Conjugate or polysaccharide platforms
Hib H. influenzae type b Capsular polysaccharide-protein conjugation
Expanded Meningococcal Coverage

Combined MenABCWY Vaccine Platforms

Pentavalent MenABCWY vaccines combine protection against meningococcal serogroups A, B, C, W, and Y in one formulation. Their availability and recommended use vary by country, product authorization, age, and risk.

Explore MenABCWY
04 / Global Epidemiology
Meningvax Research Observatory

Mapping the global challenge of meningitis.

Meningitis surveillance connects laboratory identification, epidemiological investigation, outbreak detection, and vaccination strategies. These activities are particularly important in regions affected by recurring meningococcal epidemics.

Geographic Research Focus / 04.1

The African Meningitis Belt

REGIONAL SCHEMATIC
NOT A GEOGRAPHICAL MAP
West-to-east representation of the African meningitis belt A schematic transect indicating the meningitis belt extends across parts of sub-Saharan Africa from Senegal in the west to Ethiopia in the east. Distances and borders are not geographically accurate. WEST EAST Senegal Ethiopia Surveillance Outbreak response WEST–EAST REGIONAL TRANSECT
Global Health Strategy / 04.2

Defeating Meningitis by 2030

The WHO global roadmap defines three visionary goals for reducing the burden of bacterial meningitis and improving outcomes for people affected by meningitis of any cause.

GOAL / 01 Eliminate

Bacterial meningitis epidemics

Strengthen preventive vaccination, disease surveillance and outbreak preparedness to eliminate bacterial meningitis epidemics.

GOAL / 02 50% / 70%

Reduce cases and deaths

Reduce cases of vaccine-preventable bacterial meningitis by 50% and deaths by 70%, compared with the roadmap's baseline.

GOAL / 03 Improve

Long-term care and quality of life

Reduce disability and improve quality of life for people affected by meningitis, including survivors living with long-term consequences.

05 / Diagnostic Science
CLINICAL MICROBIOLOGY / MOLECULAR DIAGNOSTICS

Inside the diagnostic laboratory.

Identifying the cause of meningitis requires the integration of clinical assessment, specimen analysis, microbiological investigations, and molecular methods. Laboratory evidence supports pathogen identification and appropriate clinical management.

Figure 05 / Molecular Analysis
Laboratory molecular analysis illustration Conceptual illustration combining a specimen tube, DNA helices and molecular detection signals. SPECIMEN ANALYSIS
Specimen / Molecular target / Signal detection
Clinical and Laboratory Integration

From biological specimen to pathogen identification.

Cerebrospinal fluid and blood investigations may provide critical information in suspected meningitis. The diagnostic strategy depends on the clinical presentation, suspected pathogen, test availability, and the urgency of treatment.

01
Microbiological Evidence Microscopy, culture and organism identification can support diagnosis and antimicrobial susceptibility assessment.
02
Molecular Detection PCR-based assays can detect pathogen nucleic acids and complement conventional microbiological methods.
03
Clinical Interpretation Laboratory findings must be interpreted alongside symptoms, examination and clinical context.
Diagnostic Research Workflow / 05.1

Four connected layers of diagnostic evidence

These elements describe complementary sources of evidence, not a mandatory chronological sequence of medical care.

EVIDENCE / 01

Clinical Assessment

Symptoms, examination, risk factors and disease progression inform the urgency and diagnostic approach.

EVIDENCE / 02

Specimen Investigation

Cerebrospinal fluid and blood tests can provide cellular, biochemical and microbiological evidence.

EVIDENCE / 03

Molecular Identification

Nucleic acid amplification can support identification of specific bacterial, viral or other pathogens.

EVIDENCE / 04

Evidence Interpretation

Results inform pathogen identification, surveillance, and clinical decisions in the appropriate context.

Scientific Methods / 05.2

Laboratory methods behind the diagnosis

Different techniques provide different forms of evidence. Culture, molecular assays, microscopy and biochemical investigations often serve complementary roles.

01

CSF Analysis

Cerebrospinal fluid investigation may assess cellular and biochemical changes consistent with meningeal inflammation.

02

Microbiological Culture

Culture can identify viable bacterial pathogens and enable antimicrobial susceptibility testing where applicable.

03

Polymerase Chain Reaction

PCR and other nucleic acid amplification techniques can detect selected pathogen-specific genetic targets.

04

Pathogen Characterization

Serogrouping, molecular typing, and genomic investigations can support epidemiological surveillance and research.

06 / Research Frontiers Genomics · Immunology · Vaccine Discovery

Decoding the next generation of meningitis research.

Molecular biology, genomic surveillance, protein characterization and immunological research provide increasingly powerful ways to investigate meningitis pathogens and improve disease-prevention strategies.

FIG. 06 / GENOMIC DISCOVERY Conceptual DNA double helix and genomic research GENOMIC ATLAS DNA / CONCEPT
Research Focus / 06.1

From genomic information to candidate vaccine antigens.

Reverse vaccinology uses pathogen genomic information to help identify potentially useful vaccine antigens. Candidate targets require laboratory validation, immunological evaluation and further development before they can become part of an effective vaccine.

GENOME ANALYSIS ANTIGEN DISCOVERY IMMUNE RESPONSE

Explore the research frontiers

Connected scientific disciplines support basic discovery, translational research, epidemiology and vaccine development.

RESEARCH / 01

Reverse Vaccinology

Genomic approaches for identifying and assessing potential pathogen antigens.

Explore the research ↗
RESEARCH / 02

Genomic Surveillance

Sequence-based investigation of circulating strains, their diversity and epidemiological relationships.

Explore the research ↗
RESEARCH / 03

Vaccine Immunology

Analysis of antibody responses, immune memory, antigen recognition and correlates of protection.

Explore the research ↗
RESEARCH / 04

Antigen Engineering

Protein characterization and design approaches for evaluating candidate vaccine components.

Explore the research ↗
RESEARCH / 05

Advanced Diagnostics

Investigation of molecular detection, pathogen identification and improved diagnostic technologies.

Explore the research ↗
RESEARCH / 06

Vaccine Platforms

Research into broader protection, multivalent formulations, delivery approaches and immune durability.

Explore the research ↗
Scientific distinction: Research-stage technologies are not equivalent to approved or recommended vaccines. Evidence of safety, effectiveness and regulatory authorization must be established for individual vaccine products.
07 / Knowledge Ecosystem Meningvax Scientific Directory

One field of study. Many scientific perspectives.

Explore the biological, clinical and public-health dimensions of meningitis through interconnected scientific knowledge hubs, research resources and specialized articles.

FEATURED SCIENTIFIC PILLAR 01 / 07
Conceptual meningitis research network VACCINES DIAGNOSIS BIOLOGY RESEARCH
FOUNDATIONAL KNOWLEDGE

Meningitis Biology

Investigate the meninges, disease mechanisms, infectious pathogens, host responses and the biological foundations of meningitis.

Explore Meningitis Biology ↗
02 / VACCINOLOGY↗

Vaccines & Immunology

MenACWY, MenB, pneumococcal and Hib vaccines, antigen recognition and immune protection.

Explore vaccine science →
03 / DIAGNOSTICS↗

Diagnosis & Laboratory Methods

CSF analysis, culture, PCR, pathogen identification and molecular diagnostics.

Explore diagnostics →
04 / CLINICAL SCIENCE↗

Prevention & Treatment

Vaccination strategies, clinical management, prevention and care informed by medical guidelines.

Explore clinical science →
05 / EPIDEMIOLOGY↗

Global Health & Surveillance

Pathogen surveillance, outbreak monitoring, public-health programs and the meningitis belt.

Explore global health →
06 / INNOVATION↗

Research & Innovation

Genomics, reverse vaccinology, antigen discovery and emerging biomedical technologies.

Explore research →
07 / RESEARCH TOOLS↗

Scientific Products

Research reagents, antibodies, recombinant proteins, assays and laboratory tools relevant to meningitis research.

Explore research tools →

Beyond these subject hubs, explore individual scientific articles, pathogen profiles, vaccine comparisons and research methods.

Browse Scientific Articles ↗
08 / Scientific Discovery Evidence · Questions · Research

Continue the scientific exploration.

Build a deeper understanding of meningitis through focused research articles, evidence-based scientific explanations and interconnected biomedical resources.

READING / 01
DISEASE BIOLOGY

What Happens During Bacterial Meningitis?

Explore pathogen invasion, host immune responses and inflammation of the meninges.

Read scientific article ↗
READING / 02
VACCINE IMMUNOLOGY

How Do Meningococcal Vaccines Work?

Understand antigen recognition, vaccine platforms, immune memory and pathogen-specific protection.

Read scientific article ↗
READING / 03
MOLECULAR DIAGNOSTICS

PCR and Culture in Meningitis Diagnosis

Learn how molecular techniques and microbiological culture provide complementary diagnostic evidence.

Read scientific article ↗
SCIENTIFIC QUESTIONS / 08.1

Essential questions. Evidence-based answers.

Direct explanations of important distinctions in meningitis biology, prevention and diagnosis.

What causes meningitis?

Meningitis is inflammation of the meninges. It may result from bacterial, viral, fungal or parasitic infections, as well as certain non-infectious conditions.

Is there one vaccine for all meningitis?

No. Different vaccines protect against specific organisms or serogroups. Meningococcal, pneumococcal and Hib vaccines prevent important causes of bacterial meningitis, but no single vaccine prevents every form.

What is the difference between MenACWY and MenB?

MenACWY vaccines target meningococcal serogroups A, C, W and Y. MenB vaccines target serogroup B. The formulations use different antigenic approaches.

How is bacterial meningitis diagnosed?

Diagnosis involves urgent clinical assessment supported by appropriate cerebrospinal fluid and blood investigations. Culture, microscopy and molecular testing may contribute to pathogen identification.

Why is genomic surveillance important?

Genomic methods help researchers investigate pathogen diversity, circulating lineages and epidemiological relationships, supporting surveillance and public-health research.

MENINGVAX / CONTINUE DISCOVERY

Explore the science. Understand the evidence.

Navigate detailed scientific topics, compare vaccine technologies, investigate laboratory methods and discover research resources across the Meningvax platform.
